NETGEAR XS508TM 8 Ports Multi 10 Gigabit Ethernet Smart Switch


8 in stock (can be backordered)

SKU: XS508TM-100NAS Category: UPC: 606449165340

S3600 Series 10G/Multi-Gigabit Ethernet Smart Switches (XS508TM)

8-Port 10G/Multi-Gigabit Ethernet Smart Switch with 2 10G SFP+ Ports

  • 8 x 10G/Multi-Gigabit ports with 2 dedicated 10G SFP+ ports
  • Energy Efficient Ethernet for maximum power savings
  • Desktop, wall mount or rack mount placement
  • Configurable L2+/L3 Lite network features
  • 1-year of NETGEAR Insight Cloud Management included


  • NETGEAR XS508TM 8-port 10G/Multi-Gigabit Smart Switch with Insight Cloud Management
  • Power cord (varies by region)
  • Wall mount kit
  • Rackmount kit
  • Installation guide


NETGEAR Insight Cloud Management: NETGEAR Insight is the easy-to-use solution for delivering centralized remote management of networks across multiple locations for small business owners, IT managers, MSPs and VARs all from a single pane-of-glass on any device.  Learn More


Backed by a NETGEAR ProSAFE Limited Lifetime Hardware Warranty.  This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller, and covers unmodified hardware, fans and internal power supplies – not software or external power supplies, and requires product registration at within 90 days of purchase; see for details. Intended for indoor use only.


  • Width: 330mm (13in)
  • Depth: 206mm (8.12in)
  • Height: 43mm (1.7in)
  • Weight: 2.2kg (4.85lb)
  • 10G/Multi-Gigabit ports: 8
  • 10G SFP+ ports: 2
  • Max MAC entries: 16K
  • Buffer size: 2MB
  • VLAN (Number Supported): 512
  • VLAN routing: Yes
  • Dynamic VLAN assignment: Yes
  • MLD Snooping: Yes
  • Static route: Yes
  • Host ARP table: 1024
  • EEE: Yes
  • DoS Prevention: Yes
  • Internal/External Power Supply/Adapter: Internal Power Supply
  • Max consumption (Watts): 32.7W
  • FAN: 2
  • Acoustic Noise Level @25C (dBA): 28.63 dBA
  • Operating Temperature: 0° to 50° C
  • MTBF: 818,977.9 hours  (93.5 years)


Additional information

Weight 8 lbs
Dimensions 17 × 14 × 5 in
Number of Ports




Switch Mounting

Management Type

Supported Speeds

, ,

Predominant Port Type

Power over Ethernet


Number of 10G Fiber Ports (SFP+)


Num 5-SPEED PORTS (100M/1G/2.5G/5G/10G)
