Netgear MS324TXUP 24-port Multi-Gigabit (2.5G) Ultra60 PoE++ Ethernet Smart Switch


5 in stock (can be backordered)

SKU: MS324TXUP-100NAS Category: UPC: 606449165258

Multi-Gigabit Ethernet Smart Switches (MS324TXUP)

24-Port Multi-Gigabit (2.5G) Ethernet Ultra60 PoE++ Smart Switch with 4 SFP+ Ports

  • 24 Multi-Gigabit 1G/2.5G ports with 4 10G SFP+ ports
  • 24 Ultra60 PoE++ ports with uninterrupted PoE
  • High powered 720W PoE budget
  • Energy Efficient Ethernet for maximum power savings
  • Quiet desktop or rackmount operation
  • Configurable L2/L2+ network features
  • NETGEAR Insight Remote Cloud Management
  • 5-year Hardware Limited Warranty 5-year Next Business Day Hardware Replacement, 90-day phone/chat support


  • NETGEAR MS324TXUP with Insight Cloud Management
  • DC power cord (varies by region)
  • Rackmount kit
  • Installation guide


This product is backed by a 5-year Hardware Limited  Warranty, 5-year Next Business Day Hardware Replacement. Click  here for coverage, availability and terms and conditions.


ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.  ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.


  • Width: 440mm
  • Depth: 310mm
  • Height: 43.2mm
  • Weight: 9.78lb (4.435kg)
  • Multi-gigabit copper ports: 24 (1G/2.5G)
  • SFP+ ports: 4
  • Number of PoE++ (802.3bt) ports: 24
  • Total PoE Power budget: 720 Watts
  • Uninterrupted PoE: Yes
  • Max MAC entries: 32K
  • Buffer size: 2 MB
  • VLAN (Number Supported): 256
  • VLAN routing: Yes
  • Dynamic VLAN assignment: Yes
  • MLD Snooping: Yes
  • Static route: Yes (32)
  • Host ARP table: 512 ARP
  • EEE: Yes
  • DoS Prevention: Yes
  • Internal/External PSU: Internal
  • Max power (worst case, all ports used, line-rate traffic): 765W
  • Fans: 3
  • Acoustic Noise Level @25C: 38.0 dBA
  • Operating Temperature: 0° to 50° C (32° to 122°F)
  • MTBF: 1,017,939 hrs (116.12 yrs)


NETGEAR Insight Remote Cloud Management

NETGEAR Insight is the easy-to-use solution for delivering centralized remote management of networks across multiple locations for small business owners, IT managers, MSPs and VARs all from a single pane-of-glass on any device.
Learn More

Additional information

Weight 14 lbs
Dimensions 21 × 16 × 5 in
Number of Ports




Switch Mounting

Management Type

Supported Speeds

Predominant Port Type

Power over Ethernet


Num of PoE Ports
